EPITOME Water Desalination
Advantages and Features
- Pure Water Production
- Efficient Waste Heat Utilization
- Low Electricity Consumption
- Economical Operating Costs
- Ease of Operation
- Maintenance Friendly
- Excellent Reliability
High Efficiency (up to 98%)
General Specifications
Capacity
-
Work Pressure
-
Designing
-
Fuel
-
Power Consumed
-
Product Catalog
Product Technical Map
Product Technical Notebook
Product Specifications
Product Introduction
The Daboo-Sanat Epitome is a desalination unit which is also applicable in situations where clean water is required for processes.
The system uses vacuum distillation to remove salt and other impurities from the seawater and convert it into high quality fresh water (<10 ppm). Waste heat from gas or diesel engines or other heat sources is used to evaporate the seawater and the system’s total electricity consumption is low.
The evaporation chamber is kept under vacuum by a water ejector driven by the seawater outlet from the evaporator. The feed water evaporators when entering the evaporators due to the vacuum condition. Water spray and droplet are partly removed from the vapor by a build-in demister. The separated water droplets fall back into the brine, which is extracted from the lower part of the unit by means of the ejector. The desalted vapor passing through the demister will be sucked into the condensers where it will be condensed by means of cold incoming seawater. The pure distilled water will be taken out by means of freshwater pump. The pure water taken out from the condensers will be controlled by a salinometer to supervise that the salinity level be satisfactory. If the salinity exceeds the preset level, the solenoid valve in the discharge line of the distiller pump is automatically activated and faulty distillate is dumped into the drain.
Selected Product Images
Standards
